High-Precision 4 axis Straight Bevel Gear Generator with Konvoid Blade

1. Control system: SIEMENS 828D system is adopted to realize four-axis control and three-axis linkage.

2. Spindle servo motor: control the main drive of the knife axis stepless speed regulation, can realize the electronic handwheel to the knife and auxiliary knife adjustment

3. Spindle servo motor: control the main drive of cutter spindle stepless speed regulation, can realize electronic handwheel tool setting and auxiliary tool adjustment.

4. Structural layout of double cutter plate holder parts: ensure reasonable space size under high rigidity performance.

5. Transmission system: the rocking table and workpiece box adopt high-precision worm gear transmission, and the structure and transmission adopt high rigidity design.

6. Electrical configuration: adopting imported parts, including CNC system, main electrical parts, bearings and seals to ensure the reliability of the machine.

7. Safety protection: Configuration of independent sealed electrical cabinet with thermostatic control device, as well as safety guard and automatic chip conveyor.

1.What are your normal lead times?

Normally, 30 to 60 days

2.What kind of package do you offer?

Standard wooden case packing

3.Do you have certification of your machine?

CE certificate

4.How about the warranty service?

24 months

5.How about the installation and commissioning?

we will enclose the production specification with the machine, and we could provide the video online to you, and our engineers are available to debug machinery overseas.

6.How to select the suitable machine?

Pls tell us the machine you need, Includes drawings,specifications and other requirements.

7.How to do it if we meet the issue during the operation?

We provide completely after sales service, and our engineers are available to service machinery overseas.

8.If we want to learn how to operate the machine, Can you provide it?

Yes, we have special service team which will offer you professional guidance.
