Successful Delivery! G800 Gear Hobbing Machine shipped to Russia

The G800 Gear Hobbing Machine is a gear machining machine for gears with 12 modules and diameters up to 800 mm. When the Russian customer came for acceptance, he was very satisfied with the machining result of the hobbing machine.

As a key transmission component in the gear hobbing machine, the screw converts the rotary motion of the motor into linear motion through precise spiral motion, driving the table or tool holder for precise displacement, ensuring high accuracy and surface finish of the gear machining.

6 axes are configured to complete the manufacture of complex gears:

1. X-axis: Responsible for radial feed, controlling the depth of feed of the tool along the radial direction of the gear.

2. Y-axis: performs transverse feed, regulating the position of the tool along the width of the gear.

3. Z-axis: responsible for axial movement, controls the up and down movement of the tool.

4. C-axis: workpiece rotating axis to make the gear rotate evenly during machining to realize all-round tooth cutting.

5. B-axis: hob rotary axis, used for hob tilt adjustment, to adapt to the processing needs of different tooth shapes.

6. W-axis: control the differential movement of the hob to realize the precise formation of gear tooth shape.

The machine tool casing, made of cast iron, has good shock absorption, stability and wear resistance, keeping the stability of the machine structure and providing customers with continuous and reliable machining support.
