Gear chamfering machine structure

The gear chamfering machine uses pneumatic or electric high-speed rotation to drive the grinding wheel for grinding work. Machine tools provide convenient and reliable equipment for automobiles, motorcycles, agricultural vehicles, engineering machinery, reduction machinery and machinery manufacturing industries. It improves the meshing accuracy of transmission components and effectively reduces transmission noise.

The prism axis is parallel to the axis of the gear to be machined. According to the principle of parallel axis gear meshing, the rib milling cutter of the gear chamfering machine uses two spur-toothed disc-shaped blades. These blades are fixed on the cutter body through screws. They are similar to the tooth shape of the gear to be processed. The two edges are in one Side engagement.

The cutter of the gear chamfering machine is pressed accordingly along the tooth shape of the gear end face to be processed. There are some extrusion burrs on the gear cutting cutter and the end and tooth surfaces of the gear teeth. The burrs on the end surface of the prismatic gear are removed by two deburring blades installed on the machine of the gear chamfering machine, which sandwich the gear to be processed. When a conductor changes from one magnetic pole range to another opposite magnetic pole range, the direction of the current in the conductor also changes at the same time. The commutator and brushes are the devices that accomplish this task. In a DC generator, the task of the commutator and brushes is to convert the alternating current in the coil into direct current and then output it. In a DC motor, the commutator and brushes are used to change the input DC power to the coil AC power. It can be seen that the commutator and brushes are essential key components in the DC motor.

The gear chamfering machine is a small precision machine tool that is professionally used in mold manufacturing, hardware machinery, machine tool manufacturing, hydraulic parts, valve manufacturing, textile machinery chamfering, and deburring of milling and planing products. Very suitable for: steel structure, boiler, pressure vessel, equipment manufacturing, shipbuilding, electric power, mold, chemical engineering, petroleum engineering, metallurgy and other welding manufacturing fields.
